DAVI

DAVI is a top-quality LED luminaire with an update possibility, designed especially for the lighting needs of the industry. The technology of this luminaire is replaceable, which means that the whole luminaire does not need to be replaced when it reaches the end of its lifespan. The availability of spare parts is guaranteed by constantly using the latest LED technology, which will always fit into the same frame.

The very robust mechanical structure of the luminaire is familiar from I-Valo’s traditional lowbay luminaires, which have been appreciated on the market for decades. Installation is easy thanks to I-Valo’s comprehensive range of fasteners for lowbay luminaires. DAVI is equipped with I-Valo’s efficient filtering technology.

  • Ta class: -30°C... +60°C (varies between models)
  • Input power range: 31 W - 156 W
  • Luminous flux of the luminaire: 4400 lm - 27 500 lm
  • Luminous efficacy of the luminaire: Up to 176 lm/W
  • Colour temperature: 4000 K
  • Enclosure rating (IP): IP65
  • Light distribution options: Medium wide and wide
  • Cover options: Tempered safety glass (clear glass, clear glass/PMMA + anti-glare film, or frosted glass).
  • Body material: Polyester-coated aluminium
  • Control options: DALI-2 or ON/OFF

DAVI
DN10M
Input power (W): 31
DAVI
DN10X
Input power (W): 31
DAVI
DA40M
Input power (W): 119
DAVI
DA40X
Input power (W): 119
DAVI
DA41M
Input power (W): 156
DAVI
DA41X
Input power (W): 156
DAVI
DN20M
Input power (W): 59
DAVI
DN20X
Input power (W): 59
DAVI
DN21M
Input power (W): 78
DAVI
DN21X
Input power (W): 78
DAVI
DN20XTW
Input power (W): 59
DAVI
DA40XTW
Input power (W): 119
DAVI
DA20M
Input power (W): 59
DAVI
DA20X
Input power (W): 59
Cable 3X
  • Cable 1.5 m (3 × 1.5 mm²)
  • Cable 4 m (3 × 1.5 mm²)
  • Free inlets plugged
Schuko plug
  • Schuko plug + 1.5 m cable (3 × 1.5 mm²)
  • Schuko plug + 4 m cable (3 × 1.5 mm²)
  • Free inlets plugged
CEE IP44 plug 3X
  • CEE IP44 plug + 1.5 m cable (3 × 1.5 mm²)
  • CEE IP44 plug + 4 m cable (3 × 1.5 mm²)
  • Free inlets plugged
CEE IP67 plug 3X
  • CEE IP67 plug + 1.5 m cable (3 × 1.5 mm²)
  • CEE IP67 plug + 4 m cable (3 × 1.5 mm²)
  • Free inlets plugged
Cable 5X
  • Cable 1.5 m (5 × 1.5 mm²)
  • Cable 4 m (5 × 1.5 mm²)
  • Free inlets plugged
Pushwire terminals 5X + 2X
  • Screwless terminal block -o- 5 × 2.5 mm² + 2 × 2.5 mm²
  • Free inlets plugged
QPD fast connection 3X
  • QPD fast connection + 4 m cable (3 × 1.5 mm²)
  • Phoenix Contact
  • Free inlets plugged
QPD fast connection 5X
  • QPD fast connection + 4 m cable (5 × 1.5 mm²)
  • Phoenix Contact
  • Free inlets plugged
Through-wired, pushwire terminals (5X + 2X) + (5X + 2X)
  • Through-wired (-o- 5 × 2,5 mm² + 2 × 2,5 mm²)
  • Inlets at either end of the luminaire
  • Free inlets plugged



DAVI M GL - Medium wide - Clear glass

DAVI M FG - Medium wide - Frosted glass

DAVI X GL - Wide - Clear glass

DAVI X FG - Wide - Frosted glass
